Themes and Visual Classes

Drop_Box Properties

This table lists all the Drop_Box properties:

Property

Description

Attributes

Borderless

Control has no border or frame.

Colors

Click the dotted Query button or double click inside the cell to access Color Selections. Valid formats for color selections include predefined system colors (e.g. Light Red), Custom (RGB codes), HTML Hex Color Codes, User Defined colors (e.g. Color17) and string Expressions.

After a color property is set, a tick in the selected color displays in the top left corner. A floating tip with a sample of the selected color displays when hovering the mouse over the color setting.

(The color tick and color tip were added in PxPlus 2018.)
(The Color Selections Query button and dialog were added in PxPlus 2020.)

Background

Background color of the control in its default state.

Button Background Color

Background color for the button on a drop box.

(Button Background Color property was added in PxPlus 2024.)

Button Tick Color

Color of the tick on the button on a drop box.

(Button Tick Color property was added in PxPlus 2024.)

Foreground

Foreground text color of the control in its default state.

Frame Color

Color of the frame/border around the control.

(Frame Color property was added in PxPlus 2024.)

Colors (States)

Button Hover Color

Background color for the button on a drop box while hovering.

(Button Hover Color property was added in PxPlus 2024.)

Button Tick Hover Color

Color of the tick on the button of a drop box while hovering.

(Button Tick Hover Color property was added in PxPlus 2024.)

Disable Background Color

Background color when the control is disabled.

(Disable Background Color property was added in PxPlus 2022.)

Disable Btn Background Color

Background color of the Drop Box button when control is disabled.

(Disable Btn Background Color property was added in PxPlus 2024.)

Disable Text Color

Foreground text color when the control is disabled.

(Disable Text Color property was added in PxPlus 2022.)

Focus Background Color

Background color when the control has focus.

(Focus Background Color property was added in PxPlus 2019.)

Focus Text Color

Text color when the control has focus.

(Focus Text Color property was added in PxPlus 2019.)

Font

Font

Click the dotted Query button or double click inside the cell to specify font properties and attributes such as Bold, Italics, etc.

Other

iNomads Class

Assign an iNomads class to the control. The iNomads class contains class attribute references used when defining the control in the HTML code generated in iNomads. An iNomads class reference must start with an alpha character (A-Z or a-z), followed by any combination of A-Z, a-z, 0-9, underscore or dash. Multiple references may be entered, separated by a space.

For a list of pre-defined classes, see iNomads Classes.

(iNomads Class property was added in PxPlus 2020.)

See Also

VarDrop_Box Properties
Themes

Visual Classes
